Width: 3.5 in
Height: 0.95 in
Length: 3.25 in
Weight: 4.1 oz
Display: LCD
RTD Type: 2, 3 or 4-wire 100Ω Pt RTD, α= 0.00385
Software: XP SP3/Vista/7 and 8 (32 and 64-bit)
Baud Rate: 250000
Materials: Plastic
Alarm Note: Programmable high and low limits; alarm is activated when temperature reaches or exceeds set limits, Alarm Delay: A cumulative alarm delay may be set in which the device will activate the alarm (via LED) only when the device has recorded a user specified time duration of dataAudible Alarm Functionality: 1 beep per second for reading alarm above/below threshold
Input Type: Internal
Calibration: Digital Calibration through Software
Data Format: °C, °F, K, Ω, °R
Form factor: Wall Mount
Samples,Max: 21504 Samples, Interval Selectable 1 Sec to 24 hrs
Sensor Type: RTD
Start Modes: Delayed Start, Immediate Start
Battery life: 4 yr, typical with reading interval of 1 min
Memory Modes: Yes
RF Frequency: 2.45 GHz
Configuration: Omega Data Logging Software, Windows PC
RH Resolution: 0.001
Response Time: Temperature: 10 min
Time Accuracy: ± 1 minute/month
Band Frequency: 2.405 to 2.475 GHz
Data Interface: Wireless, USB
Calibration Date: Automated
Measurement Type: Temperature
Pulse Resolution: ≤10 µS
LED Functionality: Green LED blinks every 5 seconds to indicate unit is logging, Blue LED blinks every 15 seconds to indicate unit is in wireless mode, Red LED blinks every 1 second to indicate alarm condition
Output Power, Max: +0dBm
RF Frequency Note: 2.45GHz IEEE 802.15.4 ultra-low power wireless transceiver with fully bi-directional communication
Relative Humidity: 0 to 95% RH non-condensing
Supply Power Note: Ultralife 9V lithium battery included; user replaceable
Response Time Note: Temperature: 10 min free air
Band Frequency Note: ISM band 2.405 to 2.475 GHz operation (channels 11 through 25) @ 250 kbps data rate
Data Interface Note: USB to mini USB, 250,000 baud for standalone operation or OM-CP-RFC1000-EXT/ OM-CP-RFC1000-EXT-EUR/OM-CP-RFC1000-IP69K required for wireless operation
Pressure Resolution: 0.02 mbar
Calibration Accuracy: Temperature: ± 0.05 °C
Battery Size and Type: Li-ion, 9V
Number of Measurements: 1
Operating Temperature, Max: 60 °C
Operating Temperature, Min: -20 °C
Temperature Measurement, Max: 850 °C
Temperature Measurement, Min: -200 °C
