Width: 26 mm
Height: 112 mm
Length: 26 mm
Memory: 3,971 Samples
Weight: 340 g
Software: Windows XP SP3 / Vista / 7 and 8 (32 and 64 - bit)
Approvals: CE
Materials: Aluminum
Resolution: Acceleration : 0.05 g
Calibration: Digital calibration through software and automatically recorded within device
Memory Note: 16 Mbit (3,971 samples)
Start Modes: Delayed Start, Immediate Start
Battery life: 60 hr
Accuracy Note: Time Accuracy : ±1 minute/month (at 20ºC, RS232 port not in use)
Pressure Type: N/A
Pressure, Max: 0 psi
Sampling Rate: 0.5 Hz (2 seconds between updates)
Time Accuracy: ±1 minute/month
Data Interface: USB
Humidity Range: 0 to 95% RH non-condensing
Millivolt Range: N/A
Measurement Type: Vibration, Acceleration
Supply Power Type: Battery
Acceleration Range: ± 50 g
Sampling Rate Note: 256 Hz (decimated to 128 Hz), FFT Period: 2 secs up to 4 hrs
Real Time Recording: May be used with PC to monitor and record instantaneous acceleration in real time
Calibration Accuracy: Accelerometer : ±1 g
Battery Size and Type: Li-ion, 9V
Number of Measurements: 4
Process Connection Size: 1/4 in
Process Connection Type: N/A
Operating Temperature, Max: 60 °C
Operating Temperature, Min: -20 °C
