INTERNAL CHANNELS
Temperature Range: -20 °C to +60 °C (-4 °F to +140 °F)
Temperature Resolution: 0.01 °C (0.018 °F)
Calibrated Accuracy: ±0.5 °C (0 °C to 50 °C)
REMOTE CHANNELS
Thermocouple Types: J, K, T, E, R, S, B, N
Thermocouple Connection: Female subminiature (SMP)
Cold Junction Compensation: Automatic, based on internal channel
Maximum Thermocouple Resistance: 1000 Ω, <100 Ω recommended
GENERAL
Memory (All channels enabled): 174,677 readings per channel
Start Modes: Software programmable immediate start or delay start, up to 6 months in advance
Real Time Recording: May be used with PC to monitor and record data in real time
LEDs: 1 per channel and 2 status LEDs
Reading Rate: 4 Hz up to 1 reading every 24 hours
Calibration: Digital calibration through software
Calibration Date: Automatically recorded within device
Battery Type: 9 V lithium battery included, user replaceable
Battery Life: 18 months typical
Data Format: Date and time stamped °C, °F, K, °R, mV, V
Time Accuracy: ±1 minute/month
Computer Interface: USB-A to micro USB cable (included); 460,800 baud
Operating System Compatibility: Windows XP SP3/7/8/10
Software Compatibility
Standard Software version 4.2.17.0 or later
Secure Software version 4.2.16.0 or later
Operating Environment:
-20 °C to +60 °C (-4 ºF to +140 ºF),
0 %RH to 95 %RH non-condensing
Dimensions: 2.70 in x 7.25 in x 1.68 in (65.6 mm x 184.2 mm x 42.7 mm)
Weight: 20 oz (580 g)
Enclosure: Black anodized aluminum
