Memory: 2 GB
Weight: 390 g
Display: Yes
Impedance: 900 Ω
Statistics: Average, Maximum, Minimum, Peak Hold, Valley Hold
Alarm modes: Adjustable, High, High/Low, Low
Cable Length: 1 m
Current Draw: 100 mA
Display Size: 72 mm (2.8 in)
EMC Standard: EN61326-1:2006, EN 55022A, EN 55022B, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6
File Formats: BMP
Relay Output: Single Pole, 24 Vdc, 1A
Accuracy Note: ± 1°C or 1%, whichever is greater
Field of view: 30:1
Housing Width: 98 mm
Output Signal: Current
Response Time: 240 ms
Sampling Time: 1 to 86,400 sec
Data Interface: RS485
Housing Height: 64 mm
Housing Length: 36 mm
Supply Voltage: 24 Vdc
Emissivity, Min: 0.2
Housing Material: Aluminum
Variables Logged: Target temp, Sensing head temp, electronics module temp, max, min, average, emissivity setting, reflected energy compensation, alarm events
Cable Length Note: 1 m (3.3') (standard), up to 30 m (98.4') (optional)
Display Size Note: 72 mm (2.83") resistive touch TFT, 320 x 240 pixels, backlit
Supply Power Note: 24 Vdc ± 5%
Repeatability Note: ± 0.5°C or 0.5%, whichever is greater
Response Time Note: 240 ms (90% response)
Settable Parameters: Alarms, Data Logging, Date, Emissivity Setting, Modbus Address, Reflected Energy Compensation, Signal Processing, Temperature Range, Temperature Unit, Time
Sensing head Material: Stainless Steel
Internal Clock Battery: 1 x BR1225 3V (not included)
Relative Humidity Note: 95% non-condensing
Relative Humidity, Max: 0.95
Spectral Response, Max: 14 μm
Spectral Response, Min: 8 μm
Temperature Resolution: 0.1 °C
Display Measuring Units: °C, °F
Configuration Parameters: Number of Samples, Sample Period, Scheduled start date and time
Process Temperature, Max: 100 °C
Process Temperature, Min: -20 °C
Emissivity Setting Method: Rotary Switch
Operating Temperature, Max: 60 °C
Electronics Module Mounting: 4 mm
Electronics Module Mounting Note: Two m4 screws for wall mounting (see diagram on data sheet)
