Weight: 750 g
Accuracy: ± 0.02 %
Mounting: Any attitude; integral mounting nut supplied
Materials: Epoxy, Die Cast Zinc, NBR, Beryllium-copper
Hysteresis: 0.0005
Sensitivity: 0.005 psi
Accuracy Note: 0.02% Regulation Accuracy (15 psi Supply Pressure Change at Midrange)
Pressure Type: Gauge
Repeatability: 0.0005
Response Time: 0.2 sec
Enclosure Ratings: IP65
Response Time Note: 0.2 sec Response Time to 50% Load Change
Media Compatibility: Air, Argon, Clean Dry Air, Nitrogen
Output Pressure, Max: 120 psi
Output Pressure, Min: 2 psi
Total Air Consumption: 0.04 SCFM
Process Connection Size: 1/4 in
Process Connection Type: NPT Female
Air Supply Pressure, Max: 150 psi
Air Supply Pressure, Min: 3 psi
Volumetric Flow Rate, Max: 10 SCFM
Operating Temperature, Max: 70 °C
Operating Temperature, Min: -20 °C
Total Air Consumption Note: 0.04 SCFM Consumption @ Mid Range
Number of Turns in Control Range: 2.5
