Height: 0 mm
Weight: 0 g
Accuracy: ± 0.1 %
RTD Type: Pt100
Bandwidth: 3 dB @ 3Hz
Linearity: ±0.1%
Hysteresis: ±0.1%
Input Type: RTD
Calibration: Trimpot
Sensor Type: Probe
Probe Length: 305 mm
Accuracy Note: ±0.1% FS (includes effects of linearity, hysteresis and repeatability)
Repeatability: ±0.1%
Probe Diameter: 6 mm
Setup Controls: Trimpot
Supply Voltage: 8 to 35 Vdc
Sheath Material: 304 Stainless Steel
Electrical Output: 4 to 20 mA
Supply Power Note: 8 to 35 Vdc; 24 Vdc recommended
Supply Power Type: DC
Thermocouple Type: N/A
Input Control Signal: N/A
Loop Resistance, Max: (Vs-8V)/0.02A
Wiring/Connector Table: 2-Wire
Temperature Coefficient: 0.00385 Ω/°C
Temperature Input Range: -18 to 149 °C
Storage Temperature, Max: 125 °C
Storage Temperature, Min: -65 °C
Operating Temperature, Max: 85 °C
Operating Temperature, Min: -25 °C
Zero Setting Adjustable Range: ±25%
