Shock: Setpoint repeats after 50 g, 10 ms duration
Height: 4.06 in
Switch: Single
Weight: 4.5 oz
Deadband: 2 to 10 psi
Diameter: 1.26 in
Approvals: UL listed
Materials: Aluminum, Brass
Vibration: Setpoint repeats after 10 g, 5 to 500 cps
Output Note: SPDT, 5 A at 250 Vac or 30 Vdc gold-clad silver contacts for loads down to 5 mA at 6 Vdc, 2 mA at 12 Vdc and 1 mA at 24 Vdc
Sensor Type: Diaphragm
Switch Type: SPDT NO/NC, Selectable
Weight Note: 128 g (4.5 oz)
Output Value: 5A @ 250 Vac
Deadband Type: Fixed
Pressure Type: Gauge
Pressure, Max: 150 psi
Pressure, Min: 10 psi
Repeatability: ± 1%
Control Output: SPDT Relay
Proof Pressure: Up to 3000 psi
Materials, Wetted: Brass, Buna-N (NBR), Stainless Steel
System Pressure, Max: 1500 psi
Additional Features 1: Buna-N O-Ring
Wiring/Connector Table: Black - N/C, Blue - N/O, Common - Violet
Process Connection Size: 1/8 in
Process Connection Type: NPT Male
Process Temperature, Max: 70 °C
Process Temperature, Min: 0 °C
Operating Temperature, Max: 75 °C
Operating Temperature, Min: -20 °C
