Weight: 230 g
Accuracy: ± 0.01 %
Frequency: 50 to 60 Hz
Input Type: Pulse
Form factor: 1/16 DIN
Time Ranges: 0.01 to 99.99sec,;0.1 to 999.9sec, 1 to 9999sec,;00:01 to 99:59min, 0.1 to 999.9min,;1 to 9999min, 00:01 to 99:59hrs,;0.1 to 999.9hrs, 1 to 9999hrs;
Display Type: Dual 4 digit LCD
Relay Rating: Electrical: 200,000 operations;Mechanical: 5,000,000 operations
Display Color: Green
Output Detail: Single pole changeover contact and single pole N/O contact
Contact Rating: OP1 10A at 250Vac/30Vdc (resistive);OP2 5A at 250Vac/30Vdc (resistive)
Control Output: 2 SPDT Relay
Supply Voltage: 7/9 to 24/30 Vac/Vdc
Enclosure Ratings: IP20, IP65
Supply Power Note: 90-250 Vac (±10%), Burden: < 5VA
Supply Power Type: AC/DC
Output Configurations: Open collector output, maximum 30Vdc, 100mA
Storage Temperature, Max: 70 °C
Storage Temperature, Min: -25 °C
Operating Temperature, Max: 50 °C
Operating Temperature, Min: 0 °C
