Weight: 388 g
Accuracy: ± 0.19 %
Hysteresis: ± 0.1% FSO
Output Signal: Millivolt
Pressure Type: Gauge
Pressure, Max: 15 psi
Pressure, Min: 0 psi
Accuracy Class: 0.1% to 0.25%
Burst Pressure: 3x Full Scale
Proof Pressure: 150% Full Scale
Supply Voltage: 24 to 32 Vdc
Linearity Error: ± 0.15%
Sensing Element: 4-active-arm Strain Gauge Bridge
Mating Connector: MIL-26482-I 10-6S
Electrical Output: mV/V
Materials, Wetted: 17-4 Stainless Steel
Zero/Balance Error: 0 V ± 10% adj
Burst Pressure Note: 300% of rated pressure
Repeatability Error: ± 0.05% FSO
Sensing Element Note: 4-active-arm bridge, using thick-film strain gages in a hermetically sealed chamber
Additional Features 1: None
Electrical Connection: MIL-26482-I 10-6P
Electrical Output Note: 0 to 5 Vdc ± 10% adjustable
Process Connection Size: 1/4 in
Process Connection Type: NPT Male
Electrical Connection Note: PTIH-10-6P connector (or equal) Mating connector (sold separately), order PT06F10-6S
Operating Temperature, Max: 121 °C
Operating Temperature, Min: -46 °C
Compensated Temperature, Max: 71 °C
Compensated Temperature, Min: 16 °C
Thermal Effect on Span error, Max: 0.003% of rdg/°F
Thermal Effect on Zero error, Max: 0.003% of rdg/°F, 0.003% of rdg/°F
