Accuracy: ± 1 %
Hysteresis: ± 0.25% FS
Output Signal: Voltage
Pressure Type: Differential
Pressure, Max: 5 inH₂O
Pressure, Min: 0 inH₂O
Response Time: 1 ms
Accuracy Class: > 0.25%
Burst Pressure: 5 psi Maximum
Supply Voltage: 8 Vdc
Linearity Error: ± 1.0%
Mating Connector: CX136-3
Electrical Output: 1 to 6 V
Zero/Balance Error: 1.0 Vdc ± 0.05
Media Compatibility: Argon, Carbon dioxide, Helium, Hydrogen, Nitrogen, Non-corrosive Dry Gasses, Oxygen
Repeatability Error: ± 0.25% FS
Additional Features 1: Differential
Electrical Connection: Pins
Process Connection Size: 5 mm
Process Connection Type: Stem
Zero/Balance Error Note: 1 Vdc ± 0.05 (3.5 ± 0.05 Vdc PX163 Series)
Operating Temperature, Max: 85 °C
Operating Temperature, Min: -40 °C
Compensated Temperature, Max: 45 °C
Compensated Temperature, Min: 5 °C
Thermal Effect on Span error, Max: ± 0.02 %FS/℃
