Shock: 50 g, operating, 1 ⁄2 sine 10 ms
Accuracy: ± 0.25 %
Stability: ± 0.25%
Vibration: 2 g from 5 to 500 Hz
Resolution: Infinite, limited only by noise level (0.005% FS)
Cable Length: 0.6 m
Power Supply: <0.2 W
Accuracy Note: ± 0.25% span RSS at constant temperature (includes linearity, repeatability and hysteresis)
Output Signal: Voltage
Pressure Note: Range Max Pressure 600 to 1100 mbar 20 psia (450 to 825 mmHg) 800 to 1100 mbar 20 psia (600 to 825 mmHg) 0 to 20 psia 30 psia (0 to 1034 mmHg)
Pressure Type: Barometric
Pressure, Max: 1100 mBar
Pressure, Min: 600 mBar
Response Time: < 10 ms
Accuracy Class: 0.1% to 0.25%
Stability Note: Long-Term Stability: ± 0.25% FS over 6 months @ 70°F
Supply Voltage: 9 to 14.5 Vdc
Sensing Element: Capacitive
Acceleration, Max: 10 g
Electrical Output: 0.1 to 5.1 V
Materials, Wetted: Alumina, Elastomer, Gold, Stainless Steel
Output Resistance: <5 Ω
Supply Power Note: 12 Vdc (9 to 14.5 Vdc max)
Response Time Note: < 10 ms to reach 90%
Media Compatibility: Air, Argon, Carbon dioxide, Helium, Hydrogen, Nitrogen, Non-corrosive Dry Gasses, Oxygen
Electrical Connection: Cable
Electrical Output Note: 0.1 to 5.1 Vdc, 3-wire
Process Connection Size: 1/8 in
Process Connection Type: Barbed Fitting
Storage Temperature, Max: 120 °C
Storage Temperature, Min: -55 °C
Operating Temperature, Max: 80 °C
Operating Temperature, Min: -20 °C
Compensated Temperature, Max: 55 °C
Compensated Temperature, Min: 0 °C
Thermal Effect on Span error, Max: ± 1% gage
Thermal Effect on Zero error, Max: ± 0.01%/°F span , ± 0.01%/°F span
