Weight: 454 g
Accuracy: ± 1 %
Accuracy Note: ± 1.0% FS
Output Signal: Voltage
Pressure Note: SELECTABLE RANGES (inH2O) 0 to 1.0, 0 to 0.5, 0 to 0.25 -0.5 to 0.5, -0.25 to 0.25, -0.125 to 0.125
Pressure Type: Differential
Pressure, Max: 1 inH₂O
Pressure, Min: 0 inH₂O
Accuracy Class: > 0.25%
Proof Pressure: Up to 10 psi
Supply Voltage: 12 to 35 Vdc
Thermal Effect: 0.02% FS/°C
Compatible Meters: DP24-E, DP25B-E, DP41-E
Electrical Output: 0 to 5 or 0 to 10 V
Enclosure Ratings: IP65, NEMA Type 4
Enclosure Material: Enamel coated 18GA steel
Media Compatibility: Air, Argon, Carbon dioxide, Helium, Hydrogen, Nitrogen, Non-corrosive Dry Gasses, Oxygen
Additional Features 1: None
Electrical Connection: Screw Terminal
Electrical Output Note: None
Process Connection Note: 0.2" hose barbs [use 0.188" (3 ⁄16") flexible tubing]
Process Connection Size: 3/16 in
Process Connection Type: Barbed Fitting
Operating Temperature, Max: 80 °C
Operating Temperature, Min: -18 °C
Compensated Temperature, Max: 65 °C
Compensated Temperature, Min: -4 °C
