Weight: 137 g
Accuracy: ± 0.4 %
Mounting: Mounting plate
Stability: <± 0.1
Resolution: 0.1 hPa
Warm Up Time: <1 sec
Output Signal: Voltage
Pressure Type: Barometric
Pressure, Max: 1060 mBar
Pressure, Min: 600 mBar
Response Time: <100 ms
Warm-Up Shift: <0.1 hPa (mb) maximum
Accuracy Class: > 0.25%
Burst Pressure: 29 psi Maximum
Proof Pressure: Up to 1500 hpa
Stability Note: Long Term Stability: <± 0.1 hPa (mb)/year
Supply Voltage: 9.5 to 28 Vdc
Electrical Output: 0 to 5 V
Output Resistance: <10 Ω
Supply Power Note: 9.5 to 28 Vdc (3 mA operate mode, 1 µA sleep mode) 3- or 4-wire circuit
Sensitivity Effect: <± 0.09% full scale/50°C
Zero/Balance Error: <± 0.18% full scale/50°C
Media Compatibility: Air, Argon, Carbon dioxide, Helium, Hydrogen, Nitrogen, Non-corrosive Dry Gasses, Oxygen
Electrical Connection: Removable Screw Terminal
Process Connection Size: 1/8 in
Process Connection Type: Barbed Fitting
Storage Temperature, Max: 120 °C
Storage Temperature, Min: -60 °C
Operating Temperature, Max: 60 °C
Operating Temperature, Min: -40 °C
Compensated Temperature, Max: 60 °C
Compensated Temperature, Min: -40 °C
Span Setting Adjustable Range: ± 5 mV
Zero Setting Adjustable Range: ± 5 mV
Thermal Effect on Span error, Max: ± 1% gage
