Shock: 50 g, 11 ms half-sine
Weight: 210 g
Accuracy: ± 0.25 %
Stability: ± 0.5%
Vibration: 15 g, 10 to 2000 Hz
Gauge Type: Stainless steel diaphragm,silicone oil-filled piezoresistive semiconductor sensor
Accuracy Note: ± 0.25% FS (linearity, hysteresis, repeatability); vacuum ranges ± 0.35% typ, ± 0.5% max
Output Signal: Current
Pressure Type: Gauge
Pressure, Max: 3000 psi
Pressure, Min: 0 psi
Accuracy Class: 0.1% to 0.25%
Proof Pressure: 2x Full Scale
Supply Voltage: 12 to 30 Vdc
Input Resistance: (Vpower – Vmin) x 50 (1500 Ω max)
Electrical Output: 4 to 20 mA
Materials, Wetted: 17-4 Stainless Steel, 300 Stainless Steel
Supply Power Note: 12 to 30 Vdc unregulated
Zero/Balance Error: 4 mA ± 2%
Proof Pressure Note: 200% or 13,000 psi max, whichever is less
Electrical Connection: DIN 43650 C (solenoid valve)
Electrical Output Note: 4 to 20 mA (2-wire reverse polarity protected)
Process Connection Size: 1/4 in
Process Connection Type: NPT Male
Operating Temperature, Max: 71 °C
Operating Temperature, Min: -18 °C
Compensated Temperature, Max: 71 °C
Compensated Temperature, Min: -1 °C
Span Setting Adjustable Range: 16 mA ± 1% FS
