Width: 117 mm
Height: 107 mm
Length: 53 mm
Weight: 368 g
Gauge Type: Capacitance
Hysteresis: 0.02% FS
Applications: Air and HVAC, Laboratories and Scientific
Current Draw: <5 mA
Output Signal: Voltage
Pressure Type: Differential
Pressure, Max: 0.05 inH₂O
Pressure, Min: -0.05 inH₂O
Response Time: 250 ms
Accuracy Class: > 0.25%
Burst Pressure: 20 psi Maximum
Proof Pressure: Up to 15 psi
Supply Voltage: 12 to 36 Vdc
Linearity Error: 0,005
Electrical Output: 1 to 5 V
Enclosure Ratings: IP62, NEMA Type 2
Materials, Wetted: Clean, Dry, Non-corrosive Gases
Repeatability Error: 0.05% FS
Line/Static Pressure: 25 psi
Electrical Connection: Screw Terminal
Electrical Output Note: 1 to 5 Vdc (3 wire)
Process Connection Note: 1 ⁄4 barbed fittings (tubing TY-316-100)
Process Connection Size: 1/4 in
Process Connection Type: Barbed Fitting
Shunt Calibration Value: NIST cal at 25, 50, 75 and 100% FS; upscale and downscale provided
Operating Temperature, Max: 72 °C
Operating Temperature, Min: -29 °C
Compensated Temperature, Max: 57 °C
Compensated Temperature, Min: 2 °C
Thermal Effect on Zero error, Max: 0.015% rdg/°F , 0.015% FS/°F
