Shock: 50 g, 11 ms half-sine
Weight: 315 g
Accuracy: ± 0.08 %
Bandwidth: DC to 1 kHz
Stability: ± 0.1%
Vibration: ± 20 g
Compliance: RoHS 2
Accuracy Note: ± 0.08% BSL maximum (other accuracies available)
Output Signal: Current
Pressure Type: Vacuum
Pressure, Max: 1 bar
Pressure, Min: 0 bar
Response Time: <1 ms
Accuracy Class: < 0.1%
Burst Pressure: 4x Full Scale
Stability Note: Long Term Stability (1-Year): ± 0.1% FS typical
Supply Voltage: 10 to 28 Vdc
Pressure Cycles: 1 million, minimum
Sensing Element: Oil filled Piezoresistive MEMS
Trim Pot Access: Removeable Electrical Connection Cover
Electrical Output: 4 to 20 mA
Enclosure Ratings: IP65
Materials, Wetted: 316L Stainless Steel
Supply Power Note: 10 to 28 Vdc, output 4 to 20 mA
Additional Features 1: None
Electrical Connection: Cable
Insulation Resistance: 100 MΩ @ 50 Vdc
Process Connection Size: 1/4 in
Process Connection Type: BSPP Male
Operating Temperature, Max: 75 °C
Operating Temperature, Min: -40 °C
Compensated Temperature, Max: 75 °C
Compensated Temperature, Min: -29 °C
Span Setting Adjustable Range: ± 10% span
Zero Setting Adjustable Range: ± 10% span
Thermal Effect on Span error, Max: ± 0.5% span
Thermal Effect on Zero error, Max: ± 0.5% span, ± 0.5% span
