Accuracy: ± 0.1 %
Diameter: 38 mm
Mounting: Mounting Bracket
Approvals: CE
Bandwidth: 3 Hz (-3 dB)
Linearity: ± 0.1%
Materials: 316 Stainless Steel
Hysteresis: ± 0.1%
Input Type: RTD (Pt100)
Input Range: -99 to 208 °C
Cable Length: 15 m
Supply Power: 8 to 35 Vdc
Output Signal: Current
Repeatability: ± 0.1%
Number of Wires: 2
Span Adjustment: ± 25 %
Wire Code Option: 1
Electrical Output: 4 to 20 mA
Enclosure Ratings: IP67, NEMA 4
Supply Power Type: DC
Loop Resistance, Max: (Vs - 8V) / 0.020 A
Electrical Connection: M12 4 pin Male
Temperature Coefficient: α = 0.00385 curve
Operating Temperature, Max: 85 °C
Operating Temperature, Min: -40 °C
Input Electrical Connection: M12 4 pin Female
Zero Setting Adjustable Range: ± 25%
