Mounting: Any (preferably with solenoid system upright)
Cv Factor: 2.8 gal/min
Materials: 316 Stainless Steel, FKM, Stainless Steel 300, Stainless Steel 400, Gold-Plated Copper
Coil Power: 8 W
Duty Cycle: 100%
Media Type: N/A
Valve Type: Direct Acting
Cycling Rate: 60 cpm
Orifice Size: 9/16 in
Supply Voltage: 120 Vac
Valve Position: Normally Closed
Enclosure Ratings: NEMA Type 4
Materials, Wetted: 316 Stainless Steel, Copper, FKM
Supply Power Note: 8 W, 110 to 120 Vac, 50 to 60 Hz
Voltage Tolerance: ±10%
Open Response Time: 100 to 200 ms
Close Response Time: 200 to 1200 ms
Media Compatibility: Hot Water, Steam
Coil Molding Material: Black Polyphenylensulphide
Operating Pressure, Max: 200 psi
Operating Pressure, Min: 0 psi
Process Connection Size: 3/8 in
Process Connection Type: NPT Male
Process Temperature, Max: 138 °C
Process Temperature, Min: -10 °C
