Shock: 55 g, half sine, 9 to 13 ms duration
Height: 53 mm
Weight: 380 g
Diameter: 74 mm
Mounting: Rail Mount
Approvals: RoHS 2 Compliant
Isolation: 1500 Vrms
Materials: Zamak Zinc Alloy, Fluorosilicone
Vibration: 1.52 mm (0.06") double amplitude, 10 to 80 Hz cycled
Compliance: 9 to 50 Vdc
Hysteresis: ± 0.1%
Input Type: Current
Protection: Termination Protection: Standard: Screw terminal barriers plus barrier strip cover
Span Error: ± 0.2% of span, Due to 50°C Change in Transmitter Temperature
Input Range: 5 to 100 mA
Supply Power: 9 to 50V
Output Detail: Max Signal for 20 mA Output: 160 mA; Zero Suppression for 4 mA Output: -30 to 60 mA; Maximum Output = 35 mA
Output Signal: Current
Repeatability: ± 0.1%
Response Time: 400 ms
Turndown Ratio: 10:1
Impedance Input: 1 Ω
Number of Wires: 2
Electrical Output: 4 to 20 mA
Enclosure Ratings: IP66, NEMA Type 4X
Relative Humidity: 0 to 100% (sealed case)
Supply Power Type: Loop Powered
Zero/Balance Error: ± 0.2% of zero suppression, Due to 50°C Change in Transmitter Temperature
Long Term Stability: ± 0.2% of zero suppression(6-month)
Electrical Connection: Screw Terminal
Power Supply Rejection: 0.01% of span/V
Storage Temperature, Max: 125 °C
Storage Temperature, Min: -55 °C
Operating Temperature, Max: 85 °C
Operating Temperature, Min: -40 °C
Water tight Proof Pressure: 5 psi
Input Electrical Connection: Screw Terminals
