Power supply: 24 VAC/DC
Frequency: 50/60 Hz
Operating voltage range: 85-110%
Power Consumption: 3.1VA (24VAC), 1.6W (24VDC)
Control method: ON/OFF, 2-PID
Installation method: digital setting by front panel keys
Display method: 11-segment digital display, PV character height 15.2mm, SV 7.1mm
Output type: voltage output (for driving SSR)
Auxiliary output: 3
Sensor input:
- Thermocouple: K, J, T, E, L, U, N, R, S, B, W, or PL II
- Platinum resistance thermometer: Pt100 or JPt100
- Infrared temperature sensor: 10 to 70°C, 60 to 120°C, 115 to 165°C, or 140 to 260°C
Analog input: 4-20 mA or 0-20 mA current input/1-5V, 0-5V, 0-10V, 0-50mV voltage input
Integral time (I): 0-9999s, 0.0-999.9s
Derivative time (D): 0-9999s, 0.0-999.9s
Control time: 0.1, 0.2, 0.5, 1-99s
Alarm setting range: -1999-9999
Input sampling time: 50 ms
Dimensions: 48 × 48 mm
Insulation resistance: 20 MΩ
Dielectric strength: 3000VAC/60s
Ambient Temperature: -10-55°C
Ambient Humidity: 25-85%RH
Weight: 120 g
