Polarity: Inverting
Output Type: 3-State
Logic Family: VHCT
Mounting Style: SMD/SMT
Quiescent Current: 1.35 mA
Moisture Sensitive: Yes
Number of Channels: 8 Channel
Supply Voltage - Max: 5.5 V
Supply Voltage - Min: 4.5 V
Number of Input Lines: 8 Input
Number of Output Lines: 8 Output
Pd - Power Dissipation: 1.302 W
Propagation Delay Time: 6.1 ns
Low Level Output Current: 8 mA
Operating Supply Current: 75 mA
High Level Output Current: - 8 mA
Operating Temperature Range: - 40 C to + 85 C
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
