Width: 1.24 mm
Height: 0.85 mm
Length: 2.1 mm
Unit Weight: 6.200 mg
Configuration: Single
Mounting Style: SMD/SMT
Transistor Polarity: NPN
Pd - Power Dissipation: 202 mW
Typical Input Resistor: 22 kOhms
Typical Resistor Ratio: 0.47
DC Current Gain hFE Max: 80
Peak DC Collector Current: 100 mA
Continuous Collector Current: 100 mA
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
DC Collector/Base Gain hfe Min: 80
Collector- Emitter Voltage VCEO Max: 50 V
