Logic Type: 3-State Output
Output Type: 3-State
Logic Family: NC7SZ
Mounting Style: SMD/SMT
Quiescent Current: 2 uA
Number of Channels: 1 Channel
Supply Voltage - Max: 5.5 V
Supply Voltage - Min: 1.65 V
Number of Input Lines: 2 Input
Number of Output Lines: 1 Output
Pd - Power Dissipation: 812 mW
Propagation Delay Time: 6.4 ns
Low Level Output Current: 32 mA
High Level Output Current: - 32 mA
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
