Width: 1.65 mm
Height: 1.05 mm
Length: 3.05 mm
Fall Time: 13 ns
Rise Time: 13 ns
Technology: Si
Unit Weight: 85 mg
Channel Mode: Enhancement
Configuration: Single
Mounting Style: SMD/SMT
Transistor Type: 1 P-Channel
Qg - Gate Charge: 6 nC
Number of Channels: 1 Channel
Transistor Polarity: P-Channel
Pd - Power Dissipation: 1.1 W
Vgs - Gate-Source Voltage: - 12 V, + 12 V
Typical Turn-On Delay Time: 7 ns
Typical Turn-Off Delay Time: 33 ns
Id - Continuous Drain Current: 3 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 5 S
Rds On - Drain-Source Resistance: 200 mOhms
Vds - Drain-Source Breakdown Voltage: 20 V
Vgs th - Gate-Source Threshold Voltage: 1.2 V
