Fall Time: 2.4 ns
Rise Time: 14 ns
Technology: Si
Unit Weight: 8.500 mg
Channel Mode: Enhancement
Configuration: Single
Qualification: AEC-Q100
Mounting Style: SMD/SMT
Qg - Gate Charge: 18 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 1.54 W
Vgs - Gate-Source Voltage: - 20 V, + 20 V
Typical Turn-On Delay Time: 6.3 ns
Typical Turn-Off Delay Time: 18 ns
Id - Continuous Drain Current: 10.7 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 39 S
Rds On - Drain-Source Resistance: 9 mOhms
Vds - Drain-Source Breakdown Voltage: 30 V
Vgs th - Gate-Source Threshold Voltage: 1.3 V
