Operating Temperature Range: -40°C to 65°C (-40°F to 149°F)
Dimensions: 470 x 191 x 121 mm (18.5 x 7.5 x 4.75 in.)
Weight: 1.332 kg (2 lb, 15 oz)
Bits per Sample: 8 for each channel, 24 total
Number of Data Channels: 3
Cable Length Available: 3 m (9.8 ft)
Length of Smart Sensor Network Cable: 0.5 m (1.6 ft)
Wind speed/gust:
Measurement Range: 0 to 76 m/sec (0 to 170 mph)
Accuracy: ±1.1 m/sec (±2 mph) or ±5% of reading, whichever is greater
Resolution: 0.5 m/sec (1.1 mph)
Starting Threshold: ≤1 m/sec (2.2 mph)
Turning radius: 108 mm (4.25 in.)
Wind Direction:
Measurement Range: 0 to 355 degrees
Accuracy: ±7 degrees
Resolution: 1 degrees (0 to 355 degrees)
Starting Threshold: 1 m/sec (2.2 mph)
Turning radius: Approximately 135 mm (5.25 in.)
Compatible with all HOBO weather station loggers, HOBOware, and HOBOlink. This sensor offers the same ease-of-use as existing Onset Smart Sensors, providing cost-effective HOBO weather stations for projects on a tight budget. Features a plug-in modular connector for easy installation, and all configuration parameters are stored in the sensor and automatically communicated to the logger, eliminating the need for programming or extensive setup.
Manual
