DC Amperage (bi-polar)
Measurement range: +/- 2 to +/- 200 (via span adjust)
Accuracy (below 100A span): +/- .5 A
Accuracy (above 100A span): +/- .5% full scale
Sensor supply: 12 - 24 DC (15 VDC min. for currents > 120 A), 35 mA no-load to 110 mA at 200 A current
Isolation: 600 VAC rms
Operating temperature range: -30 to 60C (-22 to 140F)
Humidity range: 10 - 90% non-condensing
Response time: 2 sec.
Output: (bi-polar) 4 - 20mA
Dimensions: 3.1x2.8x1.4 in. (79x70x36 mm)
Weight: 5.25 oz.
Sensor opening: 1.1x.9 in. (28x23 mm)
