Absorber Type: P type + F.S. window
Aperture: Ø12mm
Spectral Range: 0.22 - 2.1µm
Power Range: 15µW - 3W
Energy Range: 20µJ-2J
Backscattered Power: N.A.
Dimensions: Ø70 W x 19 D (mm)
Max Pulse Energy: 2J
Max Average Power Density: 0.05kW/cm²
Response Time: 2.5 s
Max Energy Density (for <100ns): 1J/cm²
Max Energy Density (for 2ms): 1J/cm²
Max Average Power: 3W
BeamTrack Functions: N.A.
Compliance: CE, UKCA, China RoHS
