Model: Pen-1.6
Design: Laser, pen-shape
Measurement range: 1 - 1000 µm
Measurement rate: max. 0.5 Hz
Measurement time: 250 - 1000 ms
Operating mode: pulsed operation
Resolution: 1 % of reading (typical)
Accuracy: 3 % of reading (typical)
Measuring distance from lens: 16 mm
Distance tolerance: ± 1 mm
Angular tolerance: ± 15 °
Size of measuring field Ø: 0.2 mm
Optical power: 650 mJ
Wavelength: 1470 nm
Laser class: 1M
Eye safety: yes
Dimensions (L x W x H) : 130 x Ø25 mm
Weight : 50 g
IP Code: IP 50
Standards: DIN EN 15042-2
Control unit: Mobile-Laser
Model: Mobile-Laser
Design: Mobile handset, Aluminium casing with protective holster
Rechargeable battery: 4 x Li-Ion
Battery life : ca. 10 h
Interface: PC: USB
Dimensions (L x W x H): 182 x 79 x 43 mm
Weight: 700 g
Standards: DIN EN 15042-2
Delivery Contents
• Sensor with connecting cable
• Control unit, including protective holster
• Li-ion battery pack, including replacement battery pack
• Quadruple charger
• OS Manager software
• Instruction manual (digital)
• Sturdy hard case
• Type-1 reference standard
• USB cable
Accessories
• Calibrations for special applications
• Tripod
