Specification
Table Travel (X): 400 mm
Table Travel (Y): 300 mm
Table Travel (Z): 300 mm
Max. Workpiece Dimensions (WxD): 920 x 505 mm
Max. Filling Height of Dielectric Tank: 215 mm
Distance Between Chuck to Table: 150 - 450 mm
Max. Workpiece Weight: 550 kg
Max. Electrode Weight: 120 kg
Table Size (WxD): 650 x 350 mm
Machine Weight: 1200 kg
Generator
Max. Working Current: 60A
Overall Power Consumption: 6KVA
Weight: 320kg
Dielectric
Tank Capacity : 380L
Filter Density: 20 μm
Filter Elements: 3pcs
