Table Travel (X DM/SM): 1000 mm
Table Travel (Y): 600 mm
Servo Travel (Z): 500 mm
Max. Workpiece Dimensions (WxD): 1670 x 990 mm
Max. Filling Height of Dielectric Tank: 460 mm
Distance Between Chuck to Table: 260 - 760 mm
Max. Workpiece Weight: 4500 kg
Max. Electrode Weight: 350 kg
Table Size (WxD): 1250 x 750 mm
Machine Weight: 5500 kg
Generator
Max. Working Current: 120A
Overall Power Consumption: 12KVA
Weight: 380kg
Dielectric
Tank Capacity: 1610 L
Filter Density: 20 μm
Filter Elements: 6 pcs
