Specification
Table Travel (X): 1500 mm
Table Travel (Y): 1000 mm
Table Travel (Z): 600 mm
Max. Workpiece Dimensions (WxD): 2070 x 1570 mm
Max. Filling Height of Dielectric Tank: 585 mm
Distance Between Chuck to Table: 580 - 1180 mm
Max. Workpiece Weight: 11000 kg
Max. Electrode Weight: 500 kg
Table Size (WxD): 1580 x 1100 mm
Machine Weight: 14700 kg
Generator
Max. Working Current: 120A
Overall Power Consumption: 12KVA
Weight: 380kg
Dielectric
Tank Capacity: 3410 L
Filter Density: 20 μm
Filter Elements: 6 pcs
