Table Travel (X DM/SM): 755 / 1550 mm
Table Travel (Y): 1000 mm
Servo Travel (Z): 600 mm
Max. Workpiece Dimensions (WxD): 2890 x 1590 mm
Max. Filling Height of Dielectric Tank: 585 mm
Distance Between Chuck to Table: 575 - 1175 mm
Max. Workpiece Weight: 10000 kg
Max. Electrode Weight: 500 kg
Table Size (WxD): 2250 x 1100 mm
Machine Weight: 15000 kg
Generator
Max. Working Current: 120A
Overall Power Consumption: 12KVA
Weight: 380kg
Dielectric
Tank Capacity: 4655 L
Filter Density: 20 μm
Filter Elements: 12 pcs
