Table Travel (X DM/SM): 1275 / 2550 mm
Table Travel (Y): 1000 mm
Table Travel (Z): 600 mm
Max. Workpiece Dimensions (WxD): 3830 x 1590 mm
Max. Filling Height of Dielectric Tank: 585 mm
Distance Between Chuck to Table: 560 - 1160 mm
Max. Workpiece Weight: 19000 kg
Max. Electrode Weight: 500 kg
Table Size (WxD): 3100 x 1100 mm
Machine Weight: 21000 kg
Generator
Max. Working Current: 120A
Overall Power Consumption: 12KVA
Weight: 380kg
Dielectric
Tank Capacity: 5910 L
Filter Density: 20 μm
Filter Elements: 12 pcs
