Table Travel (X DM/SM): 500 mm
Table Travel (Y): 400 mm
Table Travel (Z): 350 mm
Max. Workpiece Dimensions (WxD): 1020 x 710 mm
Max. Filling Height of Dielectric Tank: 355 mm
Distance Between Chuck to Table: 130 - 480 mm
Max. Workpiece Weight: 2300 kg
Max. Electrode Weight: 200 kg
Table Size (WxD): 850 x 450 mm
Machine Weight: 3000 kg
Generator
Max. Working Current: 90A
Overall Power Consumption: 10KVA
Weight: 350kg
Dielectric
Tank Capacity: 850 L
Filter Density: 20 μm
Filter Elements: 6 pcs
