OWON OEL1515 DC Electronics Load (0-150V; 0-15A; 150W)

Rated Output: 0-150V

Voltage : 0-15A

Current : 150W

Power:

Min. Operate Voltage: 0.8V@15A

CV Mode:

Range: 0-150V

Resolution: 1mV

Accuracy: 0.05%+0.05%FS

CC Mode:

Range: 0-15A

Resolution: 1mA

Accuracy: 0.05%+0.05%IFS

CR Mode:

Range: 0.05Ω - 7.5kΩ

Accuracy *1: 0.1%+0.01%R

CP Mode:

Range: 150W

Resolution: 10mW

Accuracy*1: 0.1%+0.1%FS

Dynamic Mode:

T1&T2: 0.1ms-50s

Rise/Fall Slope: 0.01A/ms-2000A/ms

Min. Rise Time: 20μs

Voltage Readback:

Range (V): 0-15V / 0-150V

Resolution: 1mV

Accuracy: 0.05%+0.05%FS

Current Readback:

Range: 0-15A

Resolution: 0.1mA

Accuracy: 0.05%+0.05%FS

Power Readback:

Range: 150W

Resolution: 10mW

Accuracy: 0.1%+0.1%FS

Protection:

Overpower Protection: >OPP, 10ms delay protect

Overvoltage Protection: >OVP, 0.1ms delay protect

Overcurrent Protection: >OCP, 0.1ms delay protect

Overtemperature: 85℃

Optional function: Battery Discharge Test，OCP Test, OPP Test， (Oredr NO. OEL-T1)

Input Power: 100V - 240Vac; 50Hz/60Hz

Interface: RS232,RS485，USB Device， SCPI support

Heat Dissipation: Internal intelligent fan with forced air cooling

Withstand Voltage: 1.5KV / AC / 5mA

Dimension ( W x H x D ): 84mm*151mm*283mm

Device Weight: ≈ 2.5kg
