Bandwidth:50MHz
Sample Rate:500MS/s
Horizontal Scale (s/div): 2ns/div - 1000s/div, step by 1 - 2 - 5
Channel:2
Display:7" color LCD, 800 x 480 pixels
Input Coupling:DC, AC , and GND
Vertical Resolution (A/D):8 bits (2 channels simultaneously)
Vertical Sensitivity:5mV/div - 5V/div (at input)
Trigger Type:Edge, Video
Trigger Mode:Auto, Normal, and Single
Waveform Math:＋, －, x, ÷, invert, FFT
Fuse:2A, T class, 250V
Dimension (W x H x D):301 x 152 x 70 mm
Device Weight:1.10 kg
Accessories: Power Cord, CD Rom, Manual, USB Cable, Probe, Probe Adjustment, Soft Bag
