Bandwidth: 100MHz
Channels: Dual
Sample Rate: Max 1GS/s
Acquisition Mode: Normal, Peak detect, Averaging
Input Coupling: DC, AC , Ground
Input Impedance: 1MΩ±2%，in parallel with 20 pF±5 pF
Probe Attenuation Factor: 1X，10X，100X，1000X
Record length: 20M
Horizontal Scale (s/div): 2 ns/div – 1000 s/div, step by 1 – 2 - 5
Vertical Sensitivity: 2 mV/div～10 V/div
Automatic Measurement: Period, Frequency, Mean, PK-PK, RMS, Max, Min, Top, Base, Amplitude, Overshoot, Preshoot, Rise Time, Fall Time, +PulseWidth, -PulseWidth, +Duty Cycle, -Duty Cycle, Delay A→B, Delay A→B, Cycle RMS, Cursor RMS, Screen Duty, Phase, +PulseCount, -PulseCount, RiseEdgeCnt, FallEdgeCnt, Area, and Cycle Area.
Waveform Math: ＋, －, ×, ÷, FFT
Waveform Storage: 16 waveforms
Trigger Type: Edge, Video
Communication Interface: USB Host and Device
Frequency Counter: available
Others:
Display: 7 inch（800*480）LCD
Dimension (L x H x D): 301mm × 152mm × 70 mm
Weight: ≈ 1.1kg
