OWON SPM8205 1 CH DC Power Multimeter (80V / 20A; 500W)

Channel: Single Channel Output

Total Output Power: 500W

Channel Output: 0 - 80V / 0 - 20A

Display: 2.8 inch color LCD display

Interface: Multiple interface options: USB Device (default) / RS232 / LAN

Dimension(W x H x D): 82mm(W) x 142mm(H) x 226mm(D)

Working Temperature: 0 - 40℃

Weight: Approx. 1.5kg

＋DC Power Specifications:

Rated Output (0℃-40℃):

Voltage: 0~80V

Current: 0~20A

Output Power : 500W

Load Regulation:

Voltage: ≤20mV

Current: ≤10mA

Power Regulation:

Voltage: ≤20mV

Current: ≤10mA

Setting Resolution:

Voltage: 10mV

Current: 1mA

Readback Resolution:

Voltage: 10mV

Current: 1mA

Value Resolution (within 12 months) (25℃±5℃):

Voltage: ≤0.05%±20mV

Current: ≤0.05%±20mA

Readback Value Resolution (25℃±5℃):

Voltage: ≤0.05%±20mV

Current: ≤0.05%±20mA

Ripple/Noise(*):

Voltage(Vp-p): ≤50mVp-p

Voltage (rms): ≤20mA

Output temperature coefficient (0℃-40℃):

Voltage: 100ppm/℃

Current: 200ppm/℃

Readback temperature coefficient:

Voltage: 100ppm/℃

Current: 200ppm/℃

Response Time(50%-100% rated load): ≤5.0ms

Storage: 4 groups of data

* Noise bandwidth 20MHz, ripple bandwidth 1MHz, connect 10uF electrolytic capacitor in parallel with 0.1uF ceramic capacitor to the output terminal for testing.:

＋Multimeter Specifications:

Full Scale Reading:  4½ digits

Auto Range:  √

Measure:  Voltage, Current, Capacitance, Resistance, Continue，Diode(0-2V) test

Capacitance:  20.000nF,200.00nF,2.0000uF,20.000uF,200.00uF, 2.0000mF: ±(3.0%±10digit)

Voltage:

DCV:

200.00mV: ±(0.3%±10digit),

2.0000V, 20.000V, 200.00V,1000V: ±(0.3%±5digit),

ACV:

200.00mV, 2.0000V, 20.000V, 200.00V: ±(0.8%±10digit)

750V: ±(1%±10digit)

Current:

DCA:

200.00mA:±(0.8%±10digit),

10.000A: ±(2.5%±10digit);

ACA:

200.00mA:±(1%±10digit),

10.000A: ±(2.8%±10digit)

Impedance:

200.00Ω,2.0000kΩ,20.000kΩ,200.00kΩ,2.0000MΩ: ±(0.8%±10digit),

20.000MΩ: ±(1%±3digit);

100MΩ: ±(5%±10digit)
