Specifications
Bandwidth 50MHz
Sample rate(Real time) 250MS/s
Record Length 5K
Channels 2 + 1 Channel multi
Input Coupling DC AC GND
Input Impedance 1MΩ±2%，in parallel with10pF±5pF
Channels Isolation 50Hz : 100 : 1, 10MHz : 40 : 1
Max Input Voltage 400V (PK - PK) (DC+AC, PK - PK) 40V (PK - PK) (DC+AC, PK - PK)
DC Gain Accuracy ±3%
DC Accuracy Average≥16: ±(3% reading + 0.05div) for △T
Probe Attenuation Factor 1X, 10X, 100X, 1000X LF Respond (AC, -3dB) ≥10Hz (at input, AC coupling, -3dB)
Sampling Rate / Relay Time Accuracy 150ps Interpolation sin(x) / x Interval (△T)
Accuracy (full bandwidth) Single: ± (1 interval time + 100ppm × reading + 0.6ns),
Average >16: ±(1 interval time + 100ppm × reading + 0.4ns)
Vertical Resolution (A/D) 8 bits resolution (2 channels simultaneously)
Vertical Sensitivity 5mV/div～5V/div Trigger Type Edge, Pulse, Video, Slope, Alternate
Trigger Mode Auto, Normal, Single
Trigger Level ±5 divisions from screen center Acquisition Mode Sample, Peak Detect, and Average Line / Field Frequency (video) NTSC, PAL, and SECAM standard Cursor Measurement △V, and △T between cursors
Automatic Measurement Vpp, Vavg, Vamp, Vrms, Freq, Period, Vmax, Vmin, Vtop, Vbase, Overshoot, Preshoot,
Rise Time, Fall Time, Delay A→B↑, Delay A→B↓, +Width, -Width, +Duty, -Duty Waveform Math ＋, －, ×, ÷, FFT
Power Supply 5.0V/1A Power Consumption ≤ 5W
Dimension (W×H×D) 170 × 120 × 18 (mm)
Weight (without package) 0.26 kg
