Bandwidth: 100 MHz
Channel: 4 channels
Sample Rate:
4-CH working: 250MSa/s
2-CH working: 500MSa/s
1-CH working: 1GSa/s
Horizontal Scale (s/div): 1ns/div～100s/div， step by 1～2～5
Sampling mode: General sampling, peak detection, average
Record Length: 10M
Input Coupling: DC, AC, GND
Input Impedance: 1MΩ±2%， in parallel with15pF±5pF
Vertical Sensitivity: 2mV/div～5V/div
Vertical Resolution (A/D): 8 bits
Max Input Voltage: 40V Peak value（DC + AC Peak value）
Bandwidth limitation: 20 MHz， full bandwidth
Probe Attenuation Factor: 1X，10X，100X，1000X
Trigger Type: Edge, Pulse, Video, Slope,
Trigger Mode: Auto, Normal, and Single
Communication Interface: USB Device (Typ-c)；USB Host ; LAN, WIFi(optional)
Power Source: 5 - 15VDC / 1.2A
Power Consumption: ≤ 8W
Dimensions (W × H × D): 190mm × 120mm × 18mm
Device Weight: 0.38 kg
