Measurement Range/ Resolution / Accuracy ±(% of reading +LBS )
DC Voltage
50.000m / 0.001mV / 0.1%+10
500.00m / 0.01mV / 0.05%+5
5.0000V / 0.0001V / 0.05%+5
50.000V / 0.001V / 0.05%+5
500.00V / 0.01V / 0.1%+5
1000.0V / 0.1V / 0.1%+10
AC Voltage
500mv-750v / 20Hz～45Hz / 1% + 30
45Hz～65Hz / 0.5% + 30
65Hz～1KHz / 0.7% + 30
DC Current
500uA / 0.01uA / 0.15%+20
5000uA / 0.1uA / 0.15%+10
50mA / 0.001mA / 0.15%+20
500mA / 0.01mA / 0.15%+10
5A / 0.0001A / 0.5%+10
10A / 0.001A / 0.5%+10
AC Current
500uA-500mA / 20Hz-1KHz / 0.5%+20
5A-10A / 20Hz-1KHz / 1.5%+20
Resistance
500Ω / 0.01Ω / 0.15%+10
5KΩ / 0.0001KΩ / 0.15%+5
50KΩ / 0.001KΩ / 0.15%+5
500KΩ / 0.01KΩ / 0.15%+5
5MΩ / 0.0001MΩ / 0.3%+5
50MΩ / 0.001MΩ / 1%+10
Frequency
10.000Hz–60MHz / - / ±(0.2%+10)
Capacitance
50nF-500uF / - / 2.5%+10
5mF-50mF / - / 5%+10
Diode
3.0000 V/ 0.0001V / -
Continuity
1000 Ω / 0.1Ω / Adjustable threshold
Temperature: K type，PT100
Max Display: 55,000 counts
Data-logging Function
Logging Duration: 15ms-9999.999s
Logging Length: 1,000 points
General
Display Screen: 3.5- inch TFT LCD with resolution 480*320
Dimensions (W×H×D): 200 x 88x 150 (mm)
Device Weight: Approximately 0.5kg
