DC power
measuring range: 400 A; 600 A; 1000 A
Resolution: 0.1 A; 1 A; 1 A
Accuracy: ± 3% + 5 digits; ± 3% + 5 digits; ± 3% + 6 digits
Overvoltage protection: 120% of the measuring range for a maximum of 60 seconds
AC power
measuring range: 400 A; 600 A; 1000 A
Resolution: 0.1 A; 1 A; 1 A
Accuracy: ± 3% + 5 digits; ± 3% + 5 digits; ± 3% + 6 digits
Frequency range: 50 ... 60 Hz
Overvoltage protection: 120% of the measuring range for a maximum of 60 seconds
DC voltage
measuring range: 4V; 40; 400V; 600V; 1000V
Resolution: 1mV; 10mV; 0.1V; 1V; 1V
Accuracy: ± 0.5% + 5 digits; ± 0.5% + 5 digits; ± 0.5% + 5 digits; ± 1% + 5 digits; ± 1% + 5 digits
Input impedance: 10 MΩ
Overvoltage protection: 1000V DC or 700V AC RMS
AC voltage
measuring range: 4V; 40; 400V; 600V; 1000V
Resolution: 1mV; 10mV; 0.1V; 1V; 1V
Accuracy: ± 1.2% + 5 digits; ± 1.2% + 5 digits; ± 1.2% + 5 digits; ± 2% + 5 digits; ± 2% + 5 digits
Input impedance: 10 MΩ
Overvoltage protection: 1000V DC or 700V AC RMS
Frequency range: 40 ... 400 Hz
Resistance
measuring range: 400 Ω; 4 kΩ; 40 kΩ; 400 kΩ; 4 MΩ; 40 MΩ
Resolution: 0.1 Ω; 1 Ω; 10 Ω; 0.1 kΩ; 1 kΩ; 10 kΩ
Accuracy: ± 1% + 5 digits; ± 1% + 5 digits; ± 1% + 5 digits; ± 1% + 5 digits; ± 1% + 5 digits; ± 2% + 5 digits
Overvoltage protection: 250V AC / DC RMS
Frequency (direct)
measuring range: 40 Hz; 400 Hz; 4 kHz; 40 kHz; 100 kHz
Resolution: 1 Hz; 1 Hz; 10 Hz; 100 Hz; 100 Hz
Accuracy: ± 0.1% + 1 digits; ± 0.1% + 1 digits; ± 0.1% + 1 digits; ± 0.1% + 1 digits; ± 0.1% + 1 digits
Measuring range: 1 ... 10V RMS, 40 Hz ... 100 kHz
Frequency (current clamp)
measuring range: 40 Hz; 400 Hz
Resolution: 0.01 Hz; 0.1 Hz
Accuracy: ± 0.1% + 1 digits; ± 0.1% + 1 digits
Frequency range: 40 ... 400 Hz (> 20 A)
Further measuring functions
Continuity test
Beep at < 40 Ω
Diode test
Indicates the forward voltage
General specifications
Measuring rate:2 ... 3 measurements per second
Display: LCD 3999 digits
Measuring range selection: Automatically
Automatic shutdown: After 30 minutes non-use, deactivatable
Maximum forceps opening: 40 mm / 1.6 in
Coefficients: 0.1 x accuracy x °C / °F*
Maximum voltage: 1000V CAT II, 600V CAT III
Maximum working height: 2000 m / 6561 ft
Operating conditions: 5 ... 35°C, < 75% rh
Storage conditions: -10 ... 35°C, < 75% rh
Power supply: 3 x 1.5V AAA batteries
Dimensions: 225 x 86 x 32 mm / 8.9 x 3.4 x 1.3 in
Weight:About 330 g / < 1 lb
Accuracies are given at ambient conditions of 18 ... 28°C, 65 ... 83°F.
*The temperature is the difference between the temperature of the operating conditions and the current ambient temperature.
Delivery Scope
1 x Digital Multimeter PCE-DC 10
1 x Pair of test leads
1 x Transport bag
3 x 1.5V AAA batteries
1 x User manual
