Maximum measurement load | 50.000 N / 5.000 kg |
Resolution | 10 N / 1 kg |
Dynamometric cell cable length | approx. 3 m |
Measurement uncertainty | ±0,05 % of the measurement value |
Gravitation map | manual setting by means of a GPS |
Measuring units | N, g, lb, oz, kg |
Calibration | with F2 calibration weights |
maximum overload | ±20 % of the measurement range |
Measurement rate | adjustable 10 values/s or 40 values/s |
Measurement function | Traction and compression measurement / PEAK function (max, min, Hold) / measurement of limit values / real time measurements by means fo the software |
Display | 61 x 34 graphic display / simultaneous indication of relevant values such as date, time and current measurement value / automatic reverse display / setting of backlight, etc... |
Menu | multilingual: German / English / Spanish |
Internal memory | 8 memory positions with 800 respective measurements |
Record | manual - pressing one button |
Interface | RS-232, 9 poles |
Printer connection | through the RS-232 interface |
Software and data cable | with software for the control and valuation l |
Operating conditions | -10 ºC ... +40 ºC |
Power supply | internal NiMH accumulator |
Accumulator duration | approx. 20 h (without backlight, approx. 45) |
Dimensions | 210 x 110 x 40 mm |
Weight | 550 g (without the dynamometric cell) |
Manufacturer:PCE-UK
Warranty: 12months
Discontinued
