Specification
Measuring range:0 ... 50 N / 0 ... 11 lbs
Resolution:0.01 N / 0.002 lbs
Pressure calibration:0.1 Mpa
Load cell:Integrated load cell with M6 connection
Measuring range: 1 ... 100% of the full scale
Measurement accuracy:± 0.5%
Units:N, kg, lb
Display:LCD
Power supply:Internal battery, 12V / 1 A power adapter
Operating temperature:10 ... 30°C / 50 ... 86°F
Relative humidity:15 ... 80% relative humidity
Weight:1 kg / 2.2 lbs
Delivery contents
1 x Dynamometer PCE-FM 500N
1 x Software
1 x USB cable
1 x Flat head adapter
1 x Hook adapter
1 x Ball head adapter
1 x Chisel head adapter
1 x Notched head adapter
1 x Adapter for extension rod
1 x Extension bar (65 mm / 26 in)
1 x Charging adapter
1 x Device case
1 x User manual
