Specification
Measurement range:0 ... 100 %
Limits of permissible absolute error of the measurements results of the mass fraction of waterΔ= 0.02 +0,025·W
Range of working temperatures:0 ... +90 °C (industrial version); 0 ... +115 °C (extended temperature range)
; 0 ... +250 °C (drying kilns)
Operation mode:continuous operation
Measurement period:0.3 ... 1.5 s
Voltage supply - Rated / - Allowable:24 (18 ... 36) VDC
Consumption current, not more than:200 mA
Input power:<0.1 W
Warm-up time at start-up:30 min
Output:RS 485 Modbus RTU, 4-20 mA [RS485: max. cable length 1,000 m; 4-20 mA: max. cable length 100 m (max. cable length to SPS unit)]
Input:digital 24 VDC
Dimension of the sensor, length:L 200 ... 1000 mm, Ø 15 ... 30 mm
(depending on the variant)
Protection class:IP54
mass:5 kg
