Input: Analog inputs:12
Resolution: 10 bits
Accuracy: 1% of full scale
Maximum sampling rates:
PicoScope: 1 MS/s[1]
PicoLog: 1 kS/s[2]
PicoSDK (block mode): 1 MS/s[1]
PicoSDK (streaming): 100 kS/s[1]
Capture memory
PicoScope (and PicoSDK block mode)
Sample rates over 100 kS/s: 8000 samples [1]
Lower sample rates: 1 million samples [1]
PicoLog (and PicoSDK streaming mode):Up to available PC storage
Analog bandwidth (–3 dB): DC to 70 kHz
Input type: Single-ended, unipolar
Input voltage range: 0 to +2.5 V
Overvoltage protection: ±30 V to ground
Input coupling: DC
Input impedance: 1 MΩ
Output:
Digital outputs (D0…D3): 2
Digital outputs (PWM): Period
Duty cycle: None
Digital outputs (all): 100 mV (typical)
Logic low voltage: 100 mV (typical)
Logic high voltage: 1 kΩ resistors in series with outputs
Current limit:
100 mV (typical)
3.3 V
1 kΩ resistors in series with outputs
Power output for sensors: 2.5 V @ 10 mA, current-limited
Environmental
Stated accuracy temperature range: 20 to 50 °C
General operation temperature: 0 to 70 °C
Relative humidity (operating): 5 to 80 %RH
Storage temperature: –20 to +80 °C
Storage humidity: 5 to 95 %RH
Physical properties
Dimensions: 45 x 100 x 140 mm (1.77 x 3.94 x 5.51 in)
Weight: <200 g (7.05 oz)
Software
PicoLog, PicoScope and PicoSDK
Available from www.picotech.com/downloads
PicoSDK example code
Available from Pico’s GitHub organization page, github.com/picotech
PicoLog user interface languages
English, French, Italian, German, Spanish, Korean, Japanese, Chinese (simplified), Russian
PicoScope user interface languages
Chinese (simplified), Chinese (traditional), Czech, Danish, Dutch, English, Finnish, French, German, Greek, Hungarian, Italian, Japanese,
Korean, Norwegian, Polish, Portuguese, Romanian, Russian, Spanish, Swedish, Turkish
PC requirementsrements
PicoLog
Microsoft Windows 7, 8 or 10, 32-bit and 64-bit versions, macOS 10.9 (Mavericks) or later, 64-bit only, Linux*, 64-bit only.
Hardware requirements as operating system.
*PicoLog for Linux is distributed as an AppImage, so you can install it without superuser permissions: see appimage.org for further
information. The software has been tested on OpenSUSE and Ubuntu.
PicoScope[4]
PicoScope Stable: Windows 7, 8 or 10 (32 or 64-bit).
PicoScope Beta: macOS 10.9 (Mavericks) or later, 64-bit only, Linux (OpenSUSE and Ubuntu).
Hardware requirements as operating system.
PicoSDK[4]
Only available for Windows. Drivers also available for 64-bit Linux and macOS.
PC interface
USB 2.0 full speed (USB 1.1 and USB 3.1 compatible)
General
Accessories supplied
USB 2.0 cable, Quick Start Guide
PC interface
USB 2.0 full speed
I/O connector
25-way D female
Power requirements
Powered from USB port
Ground fault current protection
0.9 A thermal self-resetting fuse
Compliance
European EMC and LVD standards
FCC Rules Part 15 Subpart B
RoHS compliant
