Output Voltage( DC Max): 2400V DC
Output Voltage(AC Max): 4800Vp-p
DC Current(Max): 50mA
AC Current(Max): 100mAp-p
Output Power(Max): 120VA
Frequency response (Bandwidth): 5kHz/ 2400Vp-p
Slew Rate: 60V/μs
Output impedance: 100Ω
Protect resistor: 120kΩ/120watt
Safe Loading: ≧48kΩ/4800Vp-p
Input Voltage upper limit: -5V~+5V(Max -10V~+10V)
AMPL: 500
OFFEST: ± 2400V
Monitor: 500:1
Output protection:
1. Output dedicated FUSE
2. Protection SW (switch)
3. High-speed overload protection circuit
Weight: 5.4kg
size: 320*260*150g
