Channel: 2-Each channel; Differential mode
Output Voltage( DC Max): 400V DC; 800V DC
Output Voltage(AC Max): 800Vp-p; 1600Vp-p
DC Current(Max): 65mA DC
AC Current(Max): 130mAp-p
Output Power(Max): 26VA; 52VA
Bandwidth: DC-300kHz(-3dB)
Slew Rate: 500V/μs; 1000V/μs
Output impedance: 5Ω; 10Ω
Protect resistor: 5kΩ/35watt; 10kΩ/70watt
Safe Loading: 6.15kΩ @range ±400V; 1.53kΩ @range ±100V
Input Voltage upper limit: -5V~+5V(Max -10V~+10V)
Monitor: 100:1; 200:1
Protection:
1. Output-specific FUSE
2. Output over-current protection
3. INPUT/OUTPUT input overvoltage protection
4. Over-temperature protection
Display range:
Maximum: ±400V
Minium: ±400V
Peak to peak: 0~800V
Bias voltage: ±400V
Output current: 0~65mA
Setting:
Magnification setting(AMPL): 0~100
Output offset setting: 0~±400V
Sync mode: Input by channel 1
Differential mode: Input by channel 1
