Bandwidth: DC-100MHz
Channel: 4
Sample Rate: 1GSa/s
Rise time（BNC typical）: ≤3.5 ns
Time base scope: 1ns/div～100s/div，step by 1～2～5
Sampling method: Normal sampling, peak detection, average value
Storage depth: 5K
Input coupling: DC,AC,ground
Input impedance: 1MΩ±2%，10pF±5pF parallel
Time base accuracy: ±25ppm
Interval（△T) accuracy:
Single: ±(1 sample interval + 25ppm x reading + 0.6ns),
Average >16 : ±(1sample interval time + 250ppm x reading + 0.4ns)
Vertical Sensitivity: 2mV/div～5V/div
Vertical resolution: 8bits
Input Voltage: 40V peak （DC + AC peak）
Probe attenuation coefficient: 1X，10X，100X，1000X
Isolation between channels: 50Hz:100:1，10MHz:40:1
Waveform Interpolation: Sin(x)/x
Single bandwidth: Full bandwidth
Low frequency response （AC coupling，-3db): ≥105Hz (BNC)
DC gain accuracy: ±3%
Interpretation of the scope of suppression: 100ns ～ 10s
Power: ≤8W
size: 190mm(L)×18mm（H）×120mm（W）
